Product features:

Low torque, high performance; key to cost reduction and customer focus; we can do it.

ISO5211standard actuator connection platform design, enjoy more installation convenience.

Explosion-proof valve stem and anti-static valve stem are our standard products.

We promise "zero" leakage because the true roundness of the steel balls we manufacture is unmatched.

A variety of material seat options, can be applied with different media.

Handle with locking function and other special designs.

We can also meet the special control requirements.

Full jacketed insulation.

The jacket layer maintains the temperature of the fluid.

The heat preservation medium of the jacket layer can reach 330 deg C at most.

The jacketed layer can withstand a maximum pressure of 10 bar.

Split jacketed valve products can be customized.

Technical parameters:

Nominal diameter: DN15 ~ DN200 (1/2 "~ 8")

Nominal pressure: PN16/PN25/PN40/ANSI 150LB ~ 300LB

Applicable temperature: -29 ° C ~ + 450 ° C (depending on surfacing material and structure)

Valve body material: carbon steel WCB, stainless steel CF8/CF8M, alloy steel, dual-phase steel, etc.

Ball material: stainless steel surfacing STL/Ni60/WC and other wear-resistant alloy

Connection mode: flange (GB/ANSI/DIN and other standards)

Driving mode: handle, electric, pneumatic, hydraulic

Application industry:

High viscosity fluids

Chemical

lietrochemical

Food & Beverage

Machinery and equiliment.

General liiliing
